Load capacity
1000kg
Feature 1
Open/Closed Pallet
Width
1320mm
Feature 2
Straddle leg
Fork Length
1150m
Drive
Semi-Electric
Load capacity
1000kg
Width
1320mm
Fork Length
1150m
Drive
Semi-Electric
Feature 1
Open/Closed Pallet
Feature 2
Straddle leg
Geolift SPW1025 Semi-Electric Straddle Legs Stacker 1 Ton
The Geolift SPW1025 offers 1-ton lifting capacity and a 2.5m lift height, making it ideal for stacking pallets in warehouses, factories, and logistics centers.
Original price was: RM9,869.00.RM7,310.00Current price is: RM7,310.00.
- Transport by Avertec Sdn Bhd
- Self Pick-up Available
Electric Lift System with Manual Maneuvering
Powered by a maintenance-free 12V battery, the electric lift system enables smooth, push-button vertical lifting up to 2.5 meters. Manual steering and travel provide precise control in tight or congested work areas.
Extended 2.5-Meter Lift Height
Engineered for high-level stacking, the SPW1025 reaches up to 2.5 meters, allowing efficient access to elevated racking and storage systems while reducing the need for ladders or additional equipment.
Versatile Straddle Leg Design
Adjustable straddle legs accommodate both palletized loads and non-palletized items, offering flexibility for a wide range of material types and shapes.
Durable Nylon Tyres
Heavy-duty nylon tyres ensure long-lasting performance, protect flooring from damage, and provide smooth rolling across various industrial surfaces.
Ergonomic Control and Safety
An intuitive multi-function handle integrates lifting, lowering, and braking controls. Safety features include overload protection, automatic braking, and a stable straddle base for secure operation.
| Technical Parameters | ||
|---|---|---|
|
Model |
UOM |
SPW1025 |
|
Capacity |
kg |
1000 |
|
Capacity at Highest Height |
kg |
800 |
|
Load Centre |
mm |
600 |
|
Weight (Including battery) |
kg |
494 |
|
Working Height |
mm |
2500 |
|
Overall Fork Width |
mm |
220 – 850 |
|
Inner Width of Legs |
mm |
900 – 1320 |
|
Outer Width of Legs |
mm |
1100 – 1520 |
|
Lowered Mast Height |
mm |
1896 |
|
Extended Mast Height |
mm |
3116 |
|
Overall Length |
mm |
1855 |
|
Ground Clearance |
mm |
32 |
|
Turning Radius |
mm |
1492 |
|
Lifting Speed |
mm/s |
76 / 143 |
|
Lowering Speed |
mm/s |
104 / 93 |
|
Lifting Motor |
kw |
1.6 |
|
Battery |
Ah |
LA 12V 120 |
|
Type of Operation |
|
Pedestrian |
|
Parking Brakes |
|
Manual |
|
Wheel Type |
|
Nylon |
|
Drive |
|
Manual & Semi-Electric |
Ideal Application
Warehouses & Storage Facilities
Workshops & Production Areas
Retail & Logistics
Related products
-
Sale!
![HP25 new look(1)]()
Complete RangeGeolift HP30 High Performance Hand Pallet Truck 3.0 Ton
Price range: RM1,400.00 through RM1,420.00 Select options This product has multiple variants. The options may be chosen on the product page -
Sale!
![Geolift AC25HG Hot Dipped Galvanized Hand Pallet Truck 2.5 Ton]()
Complete RangeGeolift AC25HG Hot Dipped Galvanized Hand Pallet Truck 2.5 Ton
Original price was: RM2,414.00.RM1,700.00Current price is: RM1,700.00. Select options This product has multiple variants. The options may be chosen on the product page -
Sale!
![Geolift SLP15SS Stainless Steel Scissor Lift Pallet Truck 1.5 Ton]()
